90-70을 위한 제너럴 일렉트릭 IC697CMM742 GE 이더넷 인터페이스
IC697CMM742
,IC697CMM742 이더넷 인터페이스
,GE IC697CMM742
IC697CMM742 GE Ethernet Interface for Series 90-70, Type 2 Module large inventory
Product Description:
- Connects IC697 PLC to an IEEE 802.3 CSMA/CD 10Mbps Ethernet LAN via one of three network ports: 10BaseT, 10Base2, or AUI
- 10BaseT and 10Base2 network ports provide direct connection to 10BaseT or 10Base2 network without an external transceiver
- Standard 15-pin AUI network port allows choice of 10Base5, 10Base2, 10BaseT, 10BaseF, or 10Broad36 medium with user-supplied 802.3-compatible transceiver
- Firmware is pre-loaded for easy installation and is maintained indefinitely; firmware is easily upgraded in-system from PC attached to RS-485 serial port
- The Ethernet Interface provides:
- Data exchange using configuration-based and logic-based Ethernet Global Data
- TCP/IP communication services using SRTP
- Full PLC programming and configuration services
- Comprehensive station management and diagnostic tools
Relevant models: | ||
IC660BBD120 | IC670GBI002 | IC200CHS022 |
IC660BSM021 | IC670MDL241 | IC200ALG320 |
IC660TBD024 | IC670MDL740 | IC200ERM002 |
IC660BBA020 | IC670ALG230 | IC200PBI001 |
IC660BBA025 | IC670ALG320 | IC693APU300 |
IC660BBA026 | IC670ALG630 | IC693CHS398 |
IC660BBD020 | IC670CHS001 | IC693CMM321 |
IC660BBD021 | IC697BEM731 | IC693APU301 |
IC660BBD024 | IC697CHS750 | IC693CHS392 |
IC660BBD025 | IC697CMM742 | IC693MDL340 |
IC660BBD110 | IC697CPU731 | IC693MDL645 |
IC660BBA020 | IC697CPX772 | IC693MDL740 |
IC660BBA025 | IC697MDL653 | IC693PBM200 |
IC660BBA026 | IC697MDL753 | IC693BEM331 |
IC660BBD020 | IC697PWR710 | IC694TBB032 |
IC660BBD021 | IC698CPE010 | IC694MDL645 |
IC660BBD024 | IC698CPE020 | IC694MDL742 |
IC660BBD025 | IC698ETM001 | IC695PBM300 |
IC660BBD110 | IC698CHS117 | IC695ACC400 |
Functions:
- The IC697CMM742 Ethernet Interface (Type 2) provides high performance TCP/IP communications for the IC697 PLC.
- The Ethernet Interface (Type 2) plugs into a single slot in an IC697 PLC rack and is configured with the IC641 PLC programming software. Up to four Ethernet Interface (Type 2) modules can be installed in an IC697 PLC CPU rack.
- The Ethernet Interface (Type 2) contains three network ports: 10BaseT (RJ-45 connector), 10Base2 (BNC connector), and AUI (15-pin D-connector). The Ethernet Interface automatically selects the network port in use. One network port may be used at a time.
- The 10BaseT network port permits direct connection to a 10BaseT (twisted pair) network hub or repeater without an external transceiver.
- The 10Base2 network port permits direct connection to a 10Base2 (ThinWire) network without an external transceiver.
- The AUI network port permits attachment of a usersupplied AUI (Attachment Unit Interface, or transceiver) cable.
Frequently Asked Questions:
1. Q: Can you provide discount ?
A: Yes, we are glad to offer you discount if you order more than 1 piece .
2. Q: What about your shipping terms ?
A: We can ship by DHL, UPS, FEDEX, ARAMAX, TNT and so on
3. Q:What about your lead time ?
A: We have many items in stock , you will receive it in 3-5 days .
Reference pictures:(Please contact us for detailed photos!)
